Ideal choice for areas high-demanding for high running speed and frequency. The difference between it and regular type door consists in that its driving motor and control system are all Servo type, with better movement accuracy and quicker response. Even under very high-frequency operation, the motor can keep good working condition.
Special double encoder design. In-built encoder works together with external encoder to control the running. They calibrate with each other and guarantee precise limit. Torque servo system. The motor automatically adjusts its torque every time when the door runs, according to specific load condition and running speed.
Specifications
- Max dimension: 5000 mm wide, 5000 mm high
- Max opening speed: 2.5 m/s
- Max closing speed: 1.2 m/s
- Wind resistance: Beaufort scale 10 (25 m/s)
- Work life: 15 years
- Power supply: 1-phase 220V or 3-phase 380V, 50/60 Hz
- Protection level of electric: IP55
- Available colors of fabric: Yellow, Blue, Red, Grey, White, Clear
Model characteristics
- High speed opening and closing: The running speed can reach 2 m/s, 10 times as traditional roller shutter door. This obviously improves passing effciency through it and enhances overall output.
- High frequency operation: The operation frequency can reach more than 1000 times per day without any faults. This meets need of heavy traffic in some areas.
- High-level automation: Automatic radar or other devices can be equipped, realizing auto control of the door. This enhances automation level and work efficiency.
- Excellent safety performance: Dual protection design. Every door is equipped with safety photo sensor and proximity sensor, avoiding collision accidents and protecting passing human or vehicles.
- Effective insulation: Benefiting from fast opening and closing, it can reduce the air flow between indoor and outdoor and prevent dust from entering the room. At the same time, energy is saved by reducing thermal conduction.
- Complying with GMP norm: Special design seal strcuture. PVC fabric is dust-proof and easy for cleaning
